Rail Silencers

• Sound absorbing silencers alleviate noise concerns and prevent reverberation.
• The sound absorptive properties of the material targets a peak frequency range using a mineral fiber acoustic insultation.
• NRC rating of 0.95.
• 200 or 250 AP insultation inserts are available to protect against lower frequency noise.
• Coupled with noise walls, potential for greater overall noise reduction.

The material has been tested to all applicable standards and is suitable for non-combustible construction, with a:

• 4 hour fire rating
• 0 flame spread / smoke developed

• Tested for impact, weather and moisture resistance, the material is backed by a 25-year guarantee.
• Each silencer can withstand loads of 2000 kg / 4400 lbs.

• Easily cut, nailed and screwed with simple carpentry tools and skills.
• The silencers are placed between the railway lines and come in various configurations of material, air chambers and/or low frequency acoustic materials. Each configuration is designed to target specific frequency ranges of noise that may be of special concern.
